CWDM4 CGR4 1310nm 2km 100G QSFP28 Module SMF LC Innolight TR-FC13T-H00

Name: CWDM4 CGR4 1310nm 2km 100G QSFP28 Module SMF LC Innolight TRFC13TH00
Brand: Top-Trans
Price: 1 USD

Wholesale CWDM4 CGR4 1310nm 2km 100G QSFP28 Module SMF LC Innolight TR-FC13T-H00 from china suppliers

Brand Name : Top-Trans

Model Number : TR-FC13P-H00

Certification : ISO9001, ROHS, CE, FCC

Place of Origin : Guangdong, China

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 3000pcs per month

Delivery Time : Negotiable

Packaging Details : SFP Blister Box + Anti-static Bag

Data rate : 103.125Gbps ( 4 * 25.78Gbps)

Factor Form : QSFP28

Center Wavelength : CWDM4

Transmission : 2KM SMF

Temperature : 0°C~70°C Commercial

OEM/ODM : Supported

Weight : 60 grams

Power consumption : <3.5W

Modulation : NRZ

Laser : CWDM DFB + PIN

Contact Now

Innolight TR-FC13T-H00 100G QSFP28 Module CWDM4 1310nm 2km SMF LC

Description Of Fiber Optic Transceiver

INNO LIGHT TR-FC13T-H00 is designed for 100Gigabit Ethernet and Infiniband QDR/DDR Networks within enterprise data centers. This 100G QSFP28 module uses 4 CWDM waves of 1271nm, 1291nm, 1311nm, 1331nm and mux/demux into the duplex fiber channel of 1310nm. This 100G QSFP28 module features a Duplex LC connector for the optical interface and a 38-pin connector for the electrical interface. This 100G QSFP28 module is fully compliant with the QSFP28 Multi-Source Agreement (MSA). This 100G QSFP28 module is made up of the driven 4-wavelength distributed feedback laser array (DFB) and photodiode (PIN) receiver.

Specification Of Fiber Optic Transceiver

Data Speed	103.125Gbps
Center Wavelength	CWDM4 (1271, 1291, 1311, 1331nm)
Fiber Type	Singlemode Fiber
Transmission	2km SMF
Connector	LC Duplex
Lasers	DFB + PIN
Tx power	-6.5 to +2.5 dBm
Rx sensitivity	<<-11.5 dBm
Extinction Ratio2	3.5 dB
Power Consumption	< 3.5 W

Feature Of Fiber Optic Transceiver

QSFP28 MSA compliant
4 CWDM lanes MUX/DEMUX design
Supports 103.1Gb/s aggregate bit rate
100G CWDM4 MSA Technical Spec Rev1.1
Up to 2km transmission on single mode fiber (SMF) with FEC
Operating case temperature: 0 to 70 deg C
4x25G electrical interface (OIF CEI-28G-VSR)
Maximum power consumption 3.5W
LC duplex connector
RoHS compliant

Application of Fiber Optic Transceiver

Data Center Interconnect
100GBASE-CWDM4 Interconnect

QSFP28 Transceiver List

Model	Wavelength	Distance	Fiber Type	Connector
TR-FC85S-N00	SR4 - 850nm	70/100m	MMF	MTP/MPO-12
TR-FC13R-N00	LR4 - LAN-WDM4	10km	SMF	LC Duplex
TR-FC13T-N00	CWDM4	2km	SMF	LC Duplex
TR-FC13X-N00	eCWDM4	10km	SMF	LC Duplex
TR-FC13D-N00	ER4 Lite, LAN-WDM4	30/40km	SMF	LC Duplex
TR-FC13D-NSN	ER4 lite, dual rate, LAN-WDM4	30/40km	SMF	LC Duplex
TR-VC13Txxx-N00	PSM4 Pigtail, 1310nm	2km	SMF	MTP/MPO-12
TR-VC13T-N00	PSM4 1310nm	2km	SMF	MTP/MPO-12
TR-FC13L-NSN	LR4, Dual rate, LAN-WDM4	10km	SMF	LC Duplex
TR-FC85S-E00	SR4, 850nm, CPRI	100m	MMF	MTP/MPO-12

CWDM4 CGR4 1310nm 2km 100G QSFP28 Module SMF LC Innolight TR-FC13T-H00

FAQ

Can I use your QSFP28 module with other brands 100G QSFP28 optics?

Yes, It can interoperate with other brands MSA QSFP28 CWDM4 module

What's your optic warranty terms?

1 year free replace, 3 years free repairment for non-human made hardware defects

What if I find your optics are not satifiying with our fiber link, occurs critical signal losses?

Our optics are made up of fresh new components through strict QC control on digital & optical parameters, performance and reliability tests through error detectors, eye diagrams and Industrial ovens. The qualification ratio is over 99.9%. If any quality defects occurs within the warranty, we will arrange the replace/repair service immediately.
